Specification

StyleReturn Filter
MediaCellulose
Efficiency 110µ @ β2
Outer Diameter 70.0 mm
Inner Diameter 35.0 mm
Length 85.0 mm
Δ Collapse Pressure 10 bar
Seal MaterialNitrile
Temperature Range -30 - +100°C

Description

Genuine MP Filtri 8CU040P10N return filter. Designed and manufactured in Italy this part provides exceptional performance for a range of hydraulic systems. Its advanced filtration technology removes contaminants efficiently, helping to extend the life of your machinery and reduce costly downtime. Whether you operate in manufacturing, construction, or heavy equipment industries, this filter delivers dependable protection in demanding environments while maintaining optimal system performance.

Founded in 1964 MP Filtri has a reputation for excellence and innovation and a strong commitment to social and environmental responsibility. From rigorous testing to strict compliance with international standards, each product reflects the company’s unwavering dedication to quality, reliability, and performance.

MP Filtri Brand Logo

MP Filtri Product

Genuine MP Filtri 8CU040P10N

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year MP Filtri Warranty

MP Filtri Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
10µ @ β2
Efficiency 2
Style Return Filter
Outer Diameter 70.0 mm
Inner Diameter 35.0 mm
Length 85.0 mm
Media Type Cellulose
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 10 BAR
Seal Nitrile
Temperature Range -30 - +100°C
