Summary

MicroFit MFHSU70317 Replaces the SF Filter HY20994

HY20994
HY20994
Representative product image Product image feedback

MicroFit® UltraGen III MFHSU70317 Suction Filter | Replaces the SF Filter HY20994

Brand: MicroFit
Description

The MICROFIT® UltraGen III MFHSU70317 is the MICROFIT® approved replacement to the SF Filter HY20994. Engineered and manufactured in Great Britain the MFHSU70317

Price Match
$459.00
3.09 kg
0.0065 m³
56 pcs
United Kingdom
8421.99.90
1.5 kg
0.0076 m³
56 pcs
France
8421.99.90
2.39 kg
0.009 m³
56 pcs
United States
8421.29.80.90
1.41 kg
0.0065 m³
56 pcs
Italy
8421.99.90
Shipping Terms

Description

The MICROFIT® UltraGen III MFHSU70317 is the MICROFIT® approved replacement to the SF Filter HY20994. Engineered and manufactured in Great Britain the MFHSU70317

Specification

StyleSuction Filter
MediaGlass Fiber (Anti-Static)
Efficiency 15µ @ β200
Efficiency 27µ @ β1000
Outer Diameter 79.0 mm
Inner Diameter 63.5 mm
Length 1040.5 mm
Seal MaterialViton
Temperature Range -25 - +120°C
Default Brand Logo

Same Fit-Form & Function

As the Genuine SF Filter HY20994

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
5µ @ β200
Efficiency 2 7µ @ β1000
Style Suction Filter
Outer Diameter 79.0 mm
Inner Diameter 63.5 mm
Length 1040.5 mm
Media Type Glass Fiber (Anti-Static)
Flow Direction IN-OUT
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure
Seal Viton
Temperature Range -25 - +120°C
