Argo-Hytos K3.1493-66 Replacement Special Filter

K3.1493-66
K3.1493-66
Representative product image Product image feedback

Argo-Hytos K3.1493-66 Hydraulic Filter Element

Brand: Argo-Hytos
Price Match
$2,166.00
Germany
8421.99.90
8.2 kg
0.022 m³
Italy
8421.99.90
6.5 kg
0.022 m³
France
8421.99.90
8.2 kg
0.022 m³
United Kingdom
8421.99.90
Shipping Terms

Description

Genuine Argo-Hytos K3.1493-66 Hydraulic Filter Element.

Specification

StyleHydraulic Filter Element

Description

Genuine Argo-Hytos K3.1493-66 Hydraulic Filter Element.

Argo-Hytos logo

Argo-Hytos Product

Genuine Argo-Hytos K3.1493-66

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
10µ @ β200
Efficiency 2 12µ @ β1000
Style Special Filter
Outer Diameter 143.5 mm
Inner Diameter 96.5 mm
Length 921.0 mm
Media Type Glass Fiber
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

4.0 BAR
Collapse Pressure 20 BAR
Seal Viton
Temperature Range -25 - +120°C
