Stauff RE-300-G-20-B/5 Replaces the Stauff RE300E20B
Stauff RE-300-G-20-B/5 Return Filter | Replaces the Stauff RE300E20B
RE-300-G-20-B/5
Stauff
Stauff RE300E20B
Stauff
Stauff RE300E20B
Brand:
Stauff
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 20 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 143 Inner Diameter (mm): 96,1 Length (mm): 483 Sealing: NBR, β ratio >200
Regular price
$553.00
Unit price
per
Germany
8421.99.90
4.82 kg
0.01 m³
Italy
8421.99.90
3.82 kg
0.0154 m³
France
8421.99.90
4.82 kg
United Kingdom
8421.99.90
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 20 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 143 Inner Diameter (mm): 96,1 Length (mm): 483 Sealing: NBR, β ratio >200Specification
| Style | Return Filter |
| Media | Glass Fiber |
| Efficiency 1 | 20µ @ β200 |
| Efficiency 2 | 22µ @ β1000 |
| Outer Diameter | 143.5 mm |
| Inner Diameter | 96.5 mm |
| Length | 483.0 mm |
| Bypass Pressure | 3.0 BAR bar |
| Δ Collapse Pressure | 20 bar |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
