Stauff SP-045-E-10-V/4 Replaces the Stauff SP045E10V
Stauff SP-045-E-10-V/4 Pressure Filter | Replaces the Stauff SP045E10V
SP-045-E-10-V/4
Stauff
Stauff SP045E10V
Stauff
Stauff SP045E10V
Brand:
Stauff
Description
Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 80 Inner Diameter (mm): 43,5 Length (mm): 114 Sealing: FPM, β ratio >200
Regular price
$132.00
Unit price
per
Germany
8421.99.90
0.86 kg
0.0007 m³
United Kingdom
8421.99.90
0.4 kg
0.0009 m³
France
8421.99.90
0.39 kg
0.0007 m³
Italy
8421.99.90
0.51 kg
0.0021 m³
Mexico
8421.23.00
Description
Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 80 Inner Diameter (mm): 43,5 Length (mm): 114 Sealing: FPM, β ratio >200Specification
| Style | Pressure Filter |
| Media | Glass Fiber |
| Efficiency 1 | 20µ @ β200 |
| Efficiency 2 | 22µ @ β1000 |
| Outer Diameter | 78.0 mm |
| Inner Diameter | 43.2 mm |
| Length | 116.0 mm |
| Δ Collapse Pressure | 21 bar |
| Seal Material | Viton |
| Temperature Range | -25 - +120°C |
