Stauff SP-090-F-03-B/4 Replaces the Stauff SP090F03B4
Stauff SP-090-F-03-B/4 Pressure Filter
SP-090-F-03-B/4
Stauff
Stauff
Brand:
Stauff
Description
Replacement Filter Element for Pressure Filters Micron Rating: 3 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 80 Inner Diameter (mm): 43,5 Length (mm): 329 Sealing: NBR, β ratio >200
Regular price
$595.00
Unit price
per
Germany
8421.99.90
3.75 kg
0.002 m³
United Kingdom
8421.99.90
1.71 kg
0.002 m³
Italy
8421.99.90
1.68 kg
0.0029 m³
France
8421.99.90
Description
Replacement Filter Element for Pressure Filters Micron Rating: 3 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 80 Inner Diameter (mm): 43,5 Length (mm): 329 Sealing: NBR, β ratio >200Specification
| Style | Pressure Filter |
| Media | Glass Fiber |
| Efficiency 1 | 3µ @ β200 |
| Efficiency 2 | 5µ @ β1000 |
| Outer Diameter | 78.0 mm |
| Inner Diameter | 43.0 mm |
| Length | 330.0 mm |
| Δ Collapse Pressure | 210 bar |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
Stauff Product
Genuine Stauff SP-090-F-03-B/4
Inspected to ISO 9001:2015
See Our Certification
Free 45-Day Returns
Return Policy
